1. Column: Made of high-quality cold rolled steel plate (Baosteel model Q235), specially formed
The tube drawing machine is rolled in one go. The dimensions of the facade after molding are 75mm* 75mm, and the material
Thickness is 1.2mm.
2. Cross beam: Made of high-quality cold-rolled steel plate (Baosteel model Q235), specially formed
The tube drawing machine is rolled in one go. The bottom of the beam adopts an elliptical corner design to prevent collisions
The dimension of the facade after molding is 96mm. *46mm, material thickness is 1.2mm.
3. Bed board support: Made of 25*50*0.8mm high- quality square tube, each position is
Use 5 supports.
4. Front guardrail: Made of 25*25*1.0mm square tube with hollow blow molding guard in the middle Railings.
5. Stairs: The stair poles are made of 25*50* 1.2mm elliptical tubes with no edges and corners. Anti-collision effect. The stair crossbar is made of 20*50*1.2mm square tube, and the thickness of the stair tie rod is
Only 19*1. Omm. The tie rods are made of round tubes and are connected from the columns to the stairs and with
The bed is integrated for added stability.
6. Bedside guardrail: made of 19*1. Omm round tube
